M-35 Burner

Product & Services ID : M series

0 Reviews / Write a Review

Watch Video

            SEPL is engaged in manufacturing of Commercial Gas Burner used for Commercial Kitchen Equipments and more industrial usage.  M-35 Burners designed according IS 14612-1999 standard. All the raw material is used in construction of Gas Burner is as per Is 14612 with the support of advanced technology. These M- Burners are Primarily used with Chineese Cocking Ranges which used in Commercial Kitchens of Hotels, Resturants. the flame of M burner is spreding type which require to cocking chineese food.The M-35 Burner Head is constructed with cast iron the melting temperature of same is above 1300 centigrade .  The mixing tube of M-35  Burner is made from thick mild steel with corrosion registrant which tested for salt spray test.  The air mixture and Inlet Connections are Made of Is319 Type-1 Brass and The Jet Body is made from Is-6912 Grade Brass. Very individual burners is tested for Gas Soundness, Flame Stability, Flame Travel, combustion and other tests as per IS14612. The experts in Hospitality Industry Equipments recommends heating curved surface vessels as they create powerful torch-type flames. The offered burner is broadly appreciated among our clients for its outstanding features such as precision engineering and dimensional accuracy. The M-35 Gas Burner is confirmed to work for an extended period.


  • DESIGN CODE: IS 14612-2013
  • MOC: Brass Forge Assembly & Head  CI
  • WORKING PRESSURE: 0.35 Kg/Sqcm
  • CAPACITY: 16500  Kcl/Hr
  • Usage/Application: Hotel
  • Fuel Type: LPG / PNG
  • Burner Flame : Spreading type
  • Ignition System: MANUAL

1.      High Heat Output: M-35 Burners are designed to deliver high heat output, which is essential for cooking Chinese Cuisine that requires high-temperature cooking techniques such as stir-frying.

2.     Precise Temperature Control: M Type Burners offer precise temperature control, which is important for cooking delicate dishes that require consistent temperatures.

3.     Versatility: Chinese Burners  are highly versatile and can be used for a wide range of cooking techniques, including stir-frying, deep-frying, boiling, and simmering.

4.     Large Cooking Surface: M-35 Burners  Flame  typically have a large spreading flame for  cooking surface, which allows for cooking large quantities of food at once, making them ideal for commercial kitchens that need to prepare large volumes of food quickly.

5.     Durability:  M Type Burners  are built to withstand heavy use and are typically made from high-quality materials Cast Iron & Brass,  which makes them durable and long-lasting.
